ADI LTC6820HMS#3ZZTRPBF
MSOP-16 SPI Isolators ROHS
Copied!Copied!CM.Part.#:C36019613
Package:MSOP-16
504 In stock
Delivery within 1 day
Better price for more quantity?ADI
0 In stock
0 In stock
Delivery within 1 day
Total:$0.00
ADI
0 In stock
0 In stock
Delivery within 1 day
Total:$0.00
ADI
65 In stock
65 In stock
Delivery within 1 day
Total:$0.00
| Attribute | Value |
|---|---|
| Mfr.Part.# | LTC6820HMS#3ZZTRPBF |
| Manufacturer | ADI |
| Product Category | SPI Isolators |
| RoHS | Yes |
| ECCN | EAR99 |
| Operating Temperature | -40℃~+125℃ |
| Package | MSOP-16 |
| Packaging | Tape & Reel (TR) |
| Standard Package | 2500 |
| Weight | 0.069 |
High-speed communication: Transfers data at up to 1MHz over isolated interfaces.
Low power consumption: Operates efficiently with current requirements as low as 12mA.
Wide operating range: Functions effectively within -40°C to 125°C.
Compact design: 10-lead MSOP package ensures efficient use of PCB space.
Fault tolerance: Built-in mechanisms for communication reliability in noisy environments.
Battery management systems: Uses in monitoring and balancing battery cells effectively.
Electric vehicles: Facilitates communication in automotive power systems.
Renewable energy systems: Ensures fault-tolerant operation in solar inverters.
Industrial automation: Supports robust transmission in controllers and field devices.
Test and measurement equipment: Provides isolation in precision instrumentation.
Aerospace systems: Ensures reliable operation in mission-critical avionics.
Signal integrity: Ensure cable lengths between master and slave modules remain under 10 meters for optimal performance.
Isolation barrier: Take into account a suitable isolation rating for system-level safety compliance.
Power supply decoupling: Use low-ESR capacitors near VCC for stability during operation.
Ambient conditions: Verify the IC's placement avoids excessive thermal exposure within confined designs.
Data rate selection: Match the SPI clock speed to the application requirements to avoid timing errors.
Q: Can the LTC6820 communicate over longer distances?
A: The recommended maximum cable length is 10 meters to maintain data integrity.
Q: What power supply does the LTC6820 require?
A: It supports a 3.3V or 5V supply, ensuring flexibility across designs.
Q: How does it handle noisy environments?
A: The IC uses differential signal transmission to ensure robust communication even in noisy conditions.
Q: Is the part compatible with non-isolated systems?
A: Yes, while it is optimized for isolated setups, it can also be used in non-isolated systems if required.
